ICL7107CPL 3 1/2 bit ADC Display Driver, PDIP-40 IC, 4-digit 7-segment display

The ICL7107CPL is a 3 1/2 digit ADC (Analog-to-Digital Converter) module with an in-built 4-digit 7-segment display driver. This module has a resolution of 3 1/2 bit, allowing it to display digital values from 0-1999. It operates on a single supply voltage of 0-6V DC or a dual supply of -15 to +15V. The analog input voltage is equal to the supply voltage, and it features an internal oscillator with a typical operating frequency of 48kHz. The ICL7107CPL can drive four 7-segment displays and offers 3 1/2 ADC modules. It is available in 40-pin PDIP and MQFP packages. This ADC display driver is ideal for applications that require a simple and efficient method to convert and display analog voltages. • Supply Voltage Range: This product operates within a wide supply voltage range of 0 to 6 volts of direct current, allowing for flexibility in power supply selection. • Pin Configuration: This IC features a 40-pin configuration, with each pin serving a specific function, such as power supply, analog input, and digital output, enabling seamless integration with other components. • Temperature Rating: This product has an upper temperature rating of 85 degrees Celsius, ensuring reliable operation in high-temperature environments. • Display Driver Capabilities: This IC includes a built-in 4-digit 7-segment display driver, reducing the need for additional components and simplifying the design process. • ADC Module: This product features a 3 1/2 digit ADC module with a resolution of 3 1/2 bit, allowing for accurate measurement of analog signals in the range of 0-1999.
